Description
It is widely used in blood stations, pharmaceutical factories, biochemistry, biological products and other production and scientific research units, and is also an ideal instrument for blood separation, protein precipitation, and cell separation and collection.
Features
Accurate speed control
- High torque brushless frequency conversion motor, maintenance-free, no dust, fast lifting speed.
- The flexible shaft drive system directly drives the rotor to protect the motor, with precise speed control, stable operation, low vibration and low noise.
- Precise temperature control using “Automatic thermostatic control system regulation technology”.
- Adopt imported custom-made CFC-free compressor unit, high-quality copper tube wrapped in centrifugal cavity, full tin welding technology, double-circulation pipeline, improve refrigeration efficiency
Ergonomic and structural design
- All-steel structure, 304 stainless steel centrifugal chamber, multi-layer protection design; three-stage vibration reduction, automatic balance function.
- The door cover of the instrument is equipped with double hydraulic rods to reduce the operation load; the front operation panel, the door cover is opened backwards, which comfortable to operate.
- Precise control by microcomputer processor, eye-catching red digital display, button programming;
High safety and reliability
- Induction automatic electric suction door lock, and emergency door opening device; self-check and protection of door lock, over-speed, over-temperature, unbalance, etc., safe and reliable.
- Aeronautical aluminum rotor, surface anti-corrosion, hardening treatment, high strength, fast heat conduction, improve experimental efficiency and protect sample temperature.
- 10 sets of common programs can be stored and recalled, 10 sets of acceleration rates and 10 sets of deceleration rates for users to choose flexibly to achieve the best centrifugal effect.
Specifications
| Model | CFGR-6Y |
| Max.Speed | 6000r/min |
| Max. RCF | 6600×g |
| Max.Capacity | 6×1000ml |
| Speed Accuracy | ±10r/min |
| Temperature Range | -20℃～40℃ |
| Temperature Accuracy | ±1℃ |
| Timer | 1～9h59min |
| Sound Emission | ≤65dBA |
| Electricity | AC220/110V, 50/60Hz |
| Dimension(L*D*H) | 800×740×930mm |
| Net Weight | 310kg |
| Package Dimension(L*D*H) | 1000×880×1350mm |
Matched Rotors
| Rotors No. | Rotor type | Max. Speed（rpm） | Max. Volume（ml） | Max.RCF（×g) |
| No.30298 | Swing Rotor | 4200 | 6×1000ml（Round cup） | 5100×g |
| 4200 | 6×1200ml（Elliptic cup） | 5100×g | ||
| Blood bag adapter(12 bags of 200ml blood bags or 6 bags of 400-500ml blood bags ) | ||||
| No.30223 | Angle rotor | 6000 | 6×500ml | 6600×g |
