Installation 1-Chip DLP™ Projectors

Smooth and Detailed 4K Image Quality

Quad Pixel Drive creates sharp, detailed 4K images with Rich Color Enhancer achieving vivid, accurate color. High-speed processing supports 240 Hz/1080p frame rates with latency of 8 ms or less 5 for smooth, grid-less images.

Flexible, Simple to Use, and Easy to Integrate

V/H Lens-Shift and 2.0x zoom enhance installation flexibility while two CEC-compatible HDMI ® inputs and DIGITAL LINK integrate into 4K infrastructure. Free Grid simplifies operation of Geometric Adjustment functions using only the projector remote control.

Highly Reliable Low- Maintenance Projection

Filterless heat-pipe-based cooling and hermetically sealed optical block support 20,000-hour 6 maintenance-free projection. Multi-Laser Drive Engine 7 has Failover Circuitry 8 to maintain brightness in the event a laser diode fails.

1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL].

2 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.

3 Average light-output value of all shipped products measured at center of screen in NORMAL Mode.

4 With Quad Pixel Drive.

5 Display frame rate corresponds to the input signal frame rate. Geometric adjustment features must be disabled.

6 Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m 3 of particulate matter).

7 Rate of brightness decrease varies depending on projector model.

8 Specifications vary depending on projector model.

Quad Pixel Drive for Detail-rich 4K Images with High Frame Rates

Quad Pixel Drive, Panasonic’s original 2-axis pixel-quadrupling technology, rapidly shifts each pixel vertically and horizontally to produce sharp, clear, and detail-rich 4K images for a maximum resolution of 3840 x 2160 pixels (16:9). Combined with the DMD’s high pixel-density and narrow aperture ratio, Quad Pixel Drive creates smooth, filmlike images with a superior sense of depth and definition, allowing viewers to retain complex information.

Rich Color Enhancer Produces Vivid, Accurate Colors

Rich Color Enhancer is an original Panasonic color optimization technology for 1-Chip DLP™ projectors that offers two selectable modes. Dynamic Mode balances brightness and color for clear image visibility in well-lit environments. Standard/Graphic Mode optimizes color reproduction performance by adjusting color-wheel timing to expand red-channel output, leading to more naturally vibrant red expression. Colors are deep, rich, and accurate, faithfully reflecting the content creator’s artistic intent.

Smooth Playback of 240 Hz Content

The projector smoothly plays 240 Hz/1080p video content with a minimal input-to-output latency of just 8 ms or less 1 , perfect in any application where fast response and fluid motion are important. PT-FRQ60 Series also works with Panasonic’s optional ET-SWR10 2 Real-Time Tracking Projection-Mapping System, a ready-to-use Software Development Kit (SDK) that enables image projection onto fast-moving objects at up to 240 fps, making it easy to add lifelike interactivity to your museum exhibit.

1 Display frame rate corresponds to the input signal frame rate. Geometric adjustment features must be disabled. 2 ET-SWR10 is used in conjunction with third-party devices (sold separately). Compatibility with third-party devices cannot be guaranteed. Other limitations apply. For more information, visit the ET-SWR10 webpage .

Dynamic Contrast Elevates Image Realism

Dynamic Contrast directly modulates light output to achieve high contrast with less power consumption. Digitally controlled frame-by-frame scene-linking modulation ensures precise light output adjustment for accurate contrast even when bright and dark scenes frequently interchange.

Flexible 2.0x Zoom Lens with Wide-Range V/H Lens-Shift

Versatile 2.0x optical zoom lens clears a path to stress-free installation by expanding throw-distance flexibility, giving you more freedom to choose a mounting position for the projector. Wide-range V/H Lens-Shift (Vertical: +71 %, -48 % and Horizontal: +34 %, -27 %) locates the image as desired when the ideal projector placement isn’t possible, such as in rooms with high ceilings or for projection at an angle. Adjustments are easily performed via joystick on the front panel.

Geometric Adjustment with Free Grid for Screen Adjustment via Remote Control

Free Grid simplifies operation of select Geometric Adjustment functions built into the projector. Using only the projector remote control, with no need of a connected PC, installers can correct image distortion caused by uneven surfaces or irregular objects on flat or curved screens. A grid is overlaid on the projected image, allowing the installer to reshape distorted areas by adjusting the position of node or V/H line control-points. Grids of 2 x 2, 4 x 4, 8 x 8, or 16 x 16 lines are selectable according to required granularity, and work progress is saved automatically. Grid and control-point colors are selectable to ensure clear visibility over the image.

Remote Preview Lite

Remote Preview Lite 1 allows the projectionist to check signal connectivity and to evaluate changes to the image when selected projector image adjustment settings are changed by previewing input video on a laptop screen. Remote Preview Lite works even when the projector is in Standby Mode and eliminates need for on-screen projection immediately before the presentation commences. It reduces chance of display issues before the performance, and if an error is detected, helps narrow down the possible cause to the input signal chain.

1 Requires Multi Monitoring & Control Software Version 3.2 or later.

Features 2x HDMI ® CEC-Compatible Inputs for Easy Operation

Two 4K-ready HDMI inputs support CEC commands from compatible devices, allowing the projector to turn ON/OFF with the source device. Add optional Wireless Presentation System PressIT 1 and share content from almost any device with a single press of a button. As with other compatible streaming devices, PressIT can be powered via built-in 5 V/2 A USB-DC terminal for self-contained on-ceiling installation. Compatibility with HDCP 2.3-protected 4K/60p video promotes smooth integration into your existing 4K-ready system infrastructure.

1 Availability may vary by country or region. For more information on Wireless Presentation System PressIT, please click here .

2 Device’s USB Type-C terminal requires support for DisplayPort™ ALT Mode (image output function) and DC power supply (5 V/0.9 A). Refer to the product manual for more information. Android™ devices require a dedicated app.

Note: Accessories sold separately. Operation with third-party devices cannot be guaranteed.

4K DIGITAL LINK Connection and Separate LAN Terminal

4K DIGITAL LINK transmits uncompressed 4K/60p (4.2.0) video 1 , audio 2 , and control commands through a single CAT 5e or higher STP cable for distances of up to 50 m 3 . Optional ET-YFB200G DIGITAL LINK Switcher 4 or ET-YFB100G Digital Interface Box 4 simplify installation, reduce cabling and associated cost, and enhance system reliability. Alternatively, you can transmit 100Base-TX or 10Base-T compatible control signals via a separate LAN terminal, freeing up the 4K DIGITAL LINK connection for video-signal transmission.

1 4K input signals are resized to the projector’s resolution.

2 Audio transmission depends on model’s audio capability.

3 150 m (492 ft) transmission available with ET-YFB200G DIGITAL LINK Switcher for signals up to 1080p.

4 Optional ET-YFB200G DIGITAL LINK Switcher and ET-YFB100G Digital Interface Box are not compatible with 4K signals.
