Description
Key Features:
- 7inches colorful touch panel can display the product sample’s temperature, Condenser temperature and vacuum etc in digital and curve.
- One-button start defrosting function, simple and fast.
- Rack temperature can adjustable, controllable which helps to search for freeze-drying technology.
- Compact design with a small footprint.
- With USB interface to export the data, convenient forinformation management.
- Large-volume stainless steel condenserwithout coils, which can realize independent sample pre-freezing
Reliability：
- In-situ freeze-drying design,avoid the contamination during material transfer;
- Imported brandcompressor, high cooling efficiency and fast cooling speed.
- Condenser and operation panel are made by stainless steel.
- High transparent organic glass in Drying chamber helps users to observe materials changes.
Application：
The lab series freeze dryer is suitable for freeze drying test of laboratory biomedical samples.
Widely used in drugs, biological products, chemical and food industries. On the heat-sensitive substances such as antibiotics, vaccines, blood products, hormones and other biological tissue enzymes, freeze-drying technology is applied.
Optional:
- Optional for gas interface: it can inject inert gas.
Specifications
| Model | LYO40-IS01 | LYO40-IS04 | LYO40-IS06 | LYO70-IS01 | LYO70-IS04 | LYO70-IS06 |
| Freeze Drying Area(m2) | 0.1 | 0.4 | 0.6 | 0.1 | 0.4 | 0.6 |
| Tray(Qty) | 3 | 4 | 4 | 3 | 4 | 4 |
| Tray Dimensions(W*D)(mm) | 145*275 | 195*450 | 330*440 | 145*275 | 200*450 | 335*445 |
| Height Between Trays(mm) | 45 | 45 | 50 | 45 | 45 | 50 |
| Condenser Temperature (℃) | -40 | -40 | -40 | -70 | -70 | -70 |
| Vacuum Degree(no-loading) (Pa) | 10 | 10 | 10 | 10 | 10 | 10 |
| Ice Condenser Capacity (kg/24h) | 3 | 5 | 6 | 3 | 6 | 8 |
| Refrigerant | CFC-free | CFC-free | CFC-free | CFC-free | CFC-free | CFC-free |
| Consumption(kW) | 0.75 | 1.5 | 2.3 | 1.7 | 2.6 | 3.3 |
| Electricity | AC220V/50Hz(standard), other electricity type can be customized | |||||
| External Dimensions(W*D*H)(mm) | 400*550*700 | 510*700*850 | 700*800*1300 | 400*550*700 | 510*700*850 | 700*800*1300 |
| Shipping Dimensions(W*D*H)(mm) | 730*700*810 | 1080*700*1030 | 1010*840*1300 | 950*900*1020 | 1170*850*1190 | 1260*850*1320 |
| Gross Weight(kg) | 115 | 161 | 225 | 168 | 203 | 295 |
