Description
- The intelligent cycle magnetic absorption function can realize the magnetic bead residue of any system < 0.5%;
- The magnetic rod can be dismantled to facilitate repair and change, hence prolong the device use time;
- Adjustable to multiple scales and modules, and meet the requirements of different trials;
- Adopt deep vacuum heating strip of strong wrapping ability, and reduce the bias between set temperature and actual temperature;
- Mounted with ultraviolet disinfectant device and level 11 HEPA high efficiency air filter net, and reduce aerosol pollution effectively;
- Adopt Linux system and interchange easily between Chinese and English interfac;
- Able to save program according to extraction type, convenient for search.
Specifications
| Model | NAE-0132 |
| Working voltage | AC110-240V,50-60Hz |
| Working temperature | 10-40°C |
| Working humidity | Below 80% |
| Specimen flux | 1-32, minimum specimen disposal amount:1 specimen/time |
| Extracted plate position | 2 positions |
| Applicable consumables | 96 deep well plate, 6-well reagent stripe etc. |
| Heating position | Column 2,6,8,12 can be heated |
| Temperature control | Room temperature – 99°C |
| Working volume | 20-1000ul |
| Magnetic bead recovery rate | >99.5% |
| Screen display | Graphic color control panel is ok for independent use, computer is not needed. |
| Sensation equipment | Pyroelectric technique |
| Operation interface | 10 inch, 1024 x 768 color screen, interchangeable between Chinese and English |
| Net set | Ethernet can be extended to realize remote control |
| Ultraviolet light | Yes |
| Pollution control | Level 11 HEPA filter net |
| External dimension | (405mmx350mmx465mm) mm±10mm |
| Instrument weight | 22.5kg±0.5kg |
| USB interface | Yes |
| Noise | <60db |
| Experiment storage | At most 64 accounts can be established, and each account has at most 100 program storage spaces |
| Program management | Program classified management function is built inside, and the program can be pre-set |
| Oscillatory mix | Adjustable with multiple modules and scales |
| Magnetic absorption module | One step magnetic absorption and multiple magnetic absorption |
| Magnetic absorption cycle time | 1-10 adjustable |
-
