Panasonic 原廠產品介紹

Large-Venue 3-Chip DLP™ Projectors

Note: Based on publicly available dimensions and weight for DLP™ laser projectors with 16,000 lm brightness and above as of October 2022. Optional 3-Chip DLP™ lenses 3 sold separately.

Compact Form-Factor Streamlines Workflow

PT-RQ25K Series is 40 % smaller and 35 % lighter 11 than PT-RQ22K for easy handling and workflow. Intel ® SDM standard-compatible slot expands connectivity with proprietary or third-party 12 function boards. Smart Projector Control 13 app, NFC function 14 , Remote Preview LITE, and Visual Software Suite (VSS) 15 integration streamline installation.

an Engaging Visual Experience

Quad Pixel Drive creates smooth 4K 2 images while newly improved Dynamic Contrast delivers higher white brightness and deep blacks during high-contrast scenes. Gradation Smoother reduces color banding, while Panasonic’s exclusive black-level adjustment evolves again to support seamless multi-screen projection.

Maintenance-free for Peace of Mind

Hermetically sealed optical block and high-efficiency liquid-cooling system enable maintenance-free projection for 20,000 hours 16 . Multi-Laser Drive Engine and Backup Input 17 enhance reliability for failure-proof projection. Refined power supply supports projection at up to 15,000 lm 18 on AC 100–120 V power.

1 Please refer to specifications table for brightness value of individual models. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.

2 PT-RQ25K/RQ18K only with Quad Pixel Drive [ON].

3 Excluding lenses for the PT-RQ50K projector.

4 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.

5 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.

6 Average light-output value of all shipped products measured at the center of screen in NORMAL Mode.

7 Maximum physical resolution with Quad Pixel Drive [ON].

8 PT-RQ25K/RQ18K only.

9 Only when optional TY-SB01DL DIGITAL LINK Terminal Board is loaded.

10 PT-RZ24K/RZ17K only.

11 Estimated values by cabinet volume and weight (excluding lens) according to Panasonic research.

12 Intel ® SDM standard-compatible third-party function boards sold separately. Operation of third-party devices cannot be guaranteed.

13 Check device compatibility at the App Store or the Google Play store.

14 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit available from PASS to activate NFC function. See NFC Regional Compatibility List for details.

15 Visual Software Suite is available free from PASS . For more information, visit the VSS webpage . Geometry Manager Pro is now integrated into Visual Software Suite. We recommend using Visual Software Suite with compatible projectors going forward.

16 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, NORMAL Mode, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m 3 of airborne particulate matter. Panasonic recommends checkup at point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on environment.

17 Primary and backup terminal assignment is fixed. Input signals to primary and backup inputs must be identical.

18 Maximum light output is limited to approximately 15,000 lm. Maximum value of light output is further decreased in the following cases: when a function board is installed in the slot, when the light source is deteriorating from use, or when there is dust on the optical parts.

Note: From August 2025, in accordance with the European Radio Equipment Directive (RED), the projector’s built-in email function will be removed and provided instead through Multi Monitoring & Control Software. To continue using the email function, please download the free software here .

Compact Form-Factor Streamlines Your Workflow

The World’s Smallest and Lightest 20,000 lm 1 3-Chip DLP ™ 4K 2 Projector

PT-RQ25K Series is 40 % smaller and 35 % lighter 3 than PT-RQ22K and only a little larger than our 10,000-lm-class 1-Chip DLP™ models. Unlock time-saving workflow efficiencies that save resources with transport, handling, and installation easily managed with a team of two. Explore exciting spatial design possibilities in locations previously too small to fit a 3-Chip DLP™ projector. Innovations such as miniaturized optical engine and power supply, high-efficiency cooling system, and revised optical unit materials have resulted in a game-changing design that brings elite 3-Chip DLP™ performance to events of any scale.

Note: Based on publicly available dimensions and weight for DLP™ laser projectors with 16,000 lm brightness and above as of October 2022.

3 Estimated values by cabinet volume and weight (excluding lens) according to Panasonic research.

Smart Projector Control 1 App Smooths Your Workflow

Smart Projector Control app simplifies projector setup and operation. Connection is easy: just scan the QR Code 2 displayed in the projector’s OSD menu with your smartphone camera. You can control up to 64 projectors simultaneously with operations such as on/off, input selection, and setting adjustment easily performed even with the projector in standby. You can select test patterns, adjust lens settings via new lens-control UI, and focus the projection with your smartphone camera 3 from distances of up to 30 m (98 ft) 4 . For more information, visit the Smart Projector Control webpage .

1 Check device compatibility at the App Store or the Google Play store.

2 Requires optional AJ-WM50 Series Wireless Module (sold separately). Product availability may vary by country or region.

3 Some devices do not support projector autofocus function.

4 When projecting a 300-inch image. Maximum distance is 3 m (10 ft) for a 100-inch image.

Save Prepping Time with NFC Function 1

NFC function 1 allows you to prepare your projector for setup and installation, and initialize it to factory defaults after the event, when AC power is unavailable on site or when OSD projection isn’t possible. Just place your phone on the projector’s NFC touchpoint to connect and use Smart Projector Control 2 app to read and write settings such as Projector ID and IP address. Fleets of projectors can be prepped for immediate network connection and setup the moment power rolls out on the installation site, saving time and resources. After the event, projectors can be reset to defaults while unplugged, an action that used to require OSD menu projection.

1 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit available from PASS to activate NFC function. See NFC Regional Compatibility List for details.

2 Check device compatibility at the App Store or the Google Play store.

Import and Save Your Own Test Patterns

In addition to 10 built-in test patterns, you can now import and save up to three of your own custom test-patterns to the projector. You can save your go-to test patterns or use a client’s content to calibrate the projector before the video source is connected. Access compatible BMP or PNG image files saved to USB memory via the Test Pattern menu, where they can be saved, renamed, or deleted using the projector remote control.

Note: Supports PNG (1/8/16/24/32/48/64-bit, non-transparent, alpha blending disabled) and BMP (1/8/24-bit) formats with maximum resolution of 3840 x 2400 dots (PT-RQ25K/RQ18K) or 1920 x 1200 dots (PT-RZ24K/RZ17K). For more information, please check the Operating Manual.
