Installation 1-Chip DLP™ Projectors

Note: Release date and model availability varies by country or region.

Seamless Visuals, Endless Possibilities

Quad Pixel Drive 1 creates smooth 4K 1 images without visible pixels or gridding, ideal for immersive 360° mapping attractions. Dynamic Contrast, Rich Color Enhancer, and Digital Art Mode bring out the realism of high-quality content. Project 1080/240p video 6 and, with the ET-SWR10 kit 8 , seamlessly blend content and motion in real-time.

Compact & Expandable for Easy Installation

At just 16.6 kg (36.59 lbs) and about 29% smaller than our RZ790/RZ690 models, the RQ7 Series eases the logistical burden. Optional function boards 9 for the Intel ® SDM standard-compatible SLOT, including our ET-SBFMP10 media processor, simplify complex layouts. Optional DLE Series lenses smooth the transition to 4K 1 production.

Eco-Friendly Innovation with Proven Reliability

The optical engine and light-source module comply with the IP5X Dust Protected (IEC 60529) standard 10 , while a filterless design contributes to 20,000 hours 11 of maintenance-free operation. Other aspects include using plastic parts containing about 73% recycled resins 12 and an Eco Boost mode that maintains perceived brightness while reducing energy consumption.

1 PT-RQ7L/RQ6L only.

2 When ET-DLE170 is attached. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

3 Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.

4 Average light-output value of all shipped products measured at the center of the screen in NORMAL Mode.

5 Maximum physical resolution of 4K (3840 x 2160) with Quad Pixel Drive [ON].

6 PT-RQ7L/RQ6L only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate. When using the PT-RQ7L/RQ6L to display 1080/100p, 1080/120p, or 1080/240p content, edge blending and geometric adjustment cannot be used.

7 Input signals to the PT-RZ7L/RZ6L are converted to the projector’s display resolution upon playback. YP B P R 4:2:0 format only for 4K/60p and 4K/50p signals input via DIGITAL LINK.

8 PT-RQ7L/RQ6L only. Optional ET-SWR10 Real-Time Tracking Projection-Mapping System is sold separately. For more information, please click here .

9 Optional proprietary and third-party function boards compatible with the Intel ® SDM standard-compatible SLOT are sold separately. Panasonic cannot guarantee the operation of third-party devices.

10 The Dust Protected performance of this unit is not guaranteed to be free from damage or failure under all conditions (environment with conductive dust, etc.). Please use an enclosure in environments with smoke containing oil, salt, and moisture.

11 Around this time, the light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, [NORMAL] Mode, [PICTURE MODE] set to [DYNAMIC], Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m 3 of airborne particulate matter. Panasonic recommends a checkup at the point of purchase after about 20,000 hours. Light-source lifetime may be reduced depending on environmental conditions. Replacement of parts other than the light source may be required in a shorter period. Estimated maintenance time varies depending on the environment.

12 By weight of the total mass of plastic parts in the projector main unit. Excludes projection lenses, printed circuit boards, labels, cables, connectors, electronic components, color sensor cases, optical components, ESD components, EMI component adhesives, and coatings.

Where Performance Meets Efficiency

RQ7 Series redefines 4K 1 projection, blending spectacular visuals with unparalleled efficiency. This compact 1-Chip DLP™ projector creates an entrancing experience rich in contrast and color through exclusives such as Quad Pixel Drive 1 and Rich Color Enhancer. But it’s Panasonic’s integration insight that sets it apart, with labor-saving innovations to streamline workflow. From automated multi-projection adjustment to effortless app control, the RQ7 Series makes it easy to realize your vision in museums, galleries, and beyond.

Smooth and Dimensional 4K 1 Video

Quad Pixel Drive 1 produces smooth 4K 1 images with a fascinating sense of depth. It meets the demand for absolute realism in immersive media spaces by creating detailed 4K 1 images without visible pixels or gridding, even when viewed up close. Captivate your guests with an engaging visual experience that illuminates the creator’s world and elevates your storytelling.

Rich Color Enhancer Brings the Creator’s Work to Life

Rich Color Enhancer is an original 2-mode color optimization technology. Dynamic Mode balances brightness and color for clear visibility in bright environments. Standard Mode optimizes color reproduction by expanding red-channel output for vibrant red expression. This is critical for the accurate and immersive reproduction of artwork and other color-rich content.

Digital Art Mode Increases Visual Impact

Digital Art Mode is a new picture mode that optimizes the presentation of high-quality digital artwork in museums, galleries, and immersive entertainment spaces. This mode allows you to easily enhance projection quality, emphasizing high contrast and vivid color reproduction for a more impactful viewing experience.

Note: Graphic is simulated for illustrative purposes only.

Smooth 1080/240p 1 Playback

RQ7L/RQ6L can play 1080/240p 1 video with an input-to-output latency of 8 ms 2 , smoothly reproducing fast-paced action such as eSports with minimal motion blur. The projectors also work with Panasonic’s optional ET-SWR10 Real-Time Tracking Projection-Mapping System 3 . With this ready-to-use Software Development Kit (SDK), you can link with infrared cameras and project images onto fast-moving objects at 240 Hz 1 , smoothly and seamlessly combining visual content and physical motion within your XR attraction.

1 PT-RQ7L/RQ6L only. Supports input signals up to 1080p. The display frame rate corresponds to the input signal frame rate. When using the PT-RQ7L/RQ6L to display 1080/100p, 1080/120p, or 1080/240p content, edge blending and geometric adjustment cannot be used.

2 Varies depending on the input signal, peripheral devices, and other factors.

3 Optional ET-SWR10 Real-Time Tracking Projection-Mapping System is sold separately. For more information, please click here .

Light, Quiet, and Easy to Manage

With a compact body about 29% smaller by volume and 22% lighter than the existing RZ790/RZ690 projector models, the RQ7 Series saves resources and reduces your carbon footprint in transport, storage, and installation. It can be easily carried by one person, smoothing multi-projection logistics. Furthermore, the efficient cooling system reduces operating noise to as little as 31 dB 1 , ensuring your audience stays focused on the experience and not the equipment creating it.

1 For the PT-RQ6L/RZ6L in QUIET Mode. Please see the specifications for more information.

Compatible with Existing DLE Series Lenses

The RQ7 Series is compatible with Panasonic’s DLE Series projection lenses, offering versatility for diverse production layouts and making the transition to 4K 1 more cost-effective for businesses with existing lens inventories. The projector is also compatible with the optional ET-DLE020G/DLE020 Ultra-Short-Throw Zoom Lens 2 , enabling projection in various environments. These lenses feature powered zoom 3 , focus, and vertical/horizontal lens shift, conveniently controllable via remote or the Smart Projector Control app 4 .

2 The lens fixed attachment included with the ET-DLE020G/DLE020 cannot be attached to the RQ7 Series.

3 Excluding fixed-focal-length lenses.

4 Available free from the App Store or the Google Play Store. Check device and OS compatibility before downloading and installing the app.

Wide Scalability with Intel ® SDM Standard-Compatible SLOT

The RQ7 Series is compatible with optional proprietary and third-party function boards that into its Intel ® SDM standard-compatible SLOT, making it easy to adapt, scale, and expand your projector’s connectivity. For a list of compatible function boards, please click here .

Note: The terminal layout pictured is for reference only. Optional proprietary and third-party function boards are sold separately. The operation of third-party devices cannot be guaranteed. The transmission method to the slot must be by HDMI™ signal.
