Description
It is a portable 45/0 geometry color measuring instrument and can also measure 60° gloss. 45/0 geometry is the most consistent with the visual perceptual color value, which can eliminate the specular light on the surface of the texture, and the built-in gloss sensor can accurately measure the gloss of the surface.
Features
1.Adopts 45/0 geometry (45 ring-shaped illumination, 0° viewing)
The innovative ring-shaped illumination system eliminates the direction dependence, regardless of changing the sample position; The tilt sample or the rotating instrument can achieve the high accuracy and the repeatability, will reduce the influence which the grain brings to the lowest.
The measurement on the surface of abrasive, textured and structured materials has brought great advantages.
- Compatible with 60° gloss measurement
The instrument is equipped with a high-precision gloss measurement sensor, which can measure gloss and color at the same time.
3.Color QC software
Our spectrophotometer comes with free PC color QC software, which is applicable in various industries for management of color value.
It is used for store test result, generate test report and print test report after connect with printer.
Specifications
| Model | SP-CLR600G |
| Function | Color, 60° Luster |
| Optical Geometry | 45/0(45 ring-shaped illumination,0 observe degree) |
| Measuring Aperture | φ11mm |
| Light Source | LED |
| Wavelength Range | 400-700nm |
| Wavelength Interval | 10nm |
| Sensor | High sensitivity silicon photodiode |
| Repeatability | Light splitting reflectivity：standard deviation within 0.08% |
| Color values;ΔE*ab≤0.03(After calibration, standard deviation of 30 measurements on test white board, 5 second intervals),Max.：0.05 | |
| Inter-instrument error | ΔE*ab within 0.2(BCRA color charts II, average of the 12 charts) |
| Observer Angle | 2°/ 10° |
| Illuminant | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30.DLF,NBF,TL83,TL84.U35 |
| Color Space | CIE-L*a*b, L*C*h, L*u*v, XYZ, Yxy, Reflectance
Hunterlab,Munsell MI,CMYK,RGB,HSB |
| Other Colorimetric Index | WI(ASTM E313-10,ASTM E313-73,CIE/ISO, AATCC, Hunter, Taube Berger, Ganz, Stensby)； YI(ASTM D1925，ASTM E313-00,ASTM E313-73)；Tint(ASTM E313,CIE,Ganz)
Metamerism index Milm, Stick color fastness, Color fastness ISO luminance, 8 gloss, A density, T density, M density, E density |
| Color Difference | ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00,ΔEab(Hunter),555 shade sort |
| Measuring Angle | 60° |
| Measuring Area | 5*10 mm |
| Measuring Range | 0 – 1000 GU |
| Reproducibility | 1.0 GU(0-100GU)
1.0%(100-1000GU) |
| Illuminant Life Span | 3 million measurements in 10 years |
| Data Storage | 20000 test results |
| Interface | USB |
| Screen | 2.8-inch color screen |
| Battery | Rechargeable, 10000 continuous tests, 7.4V/6000mAh |
| Operating Environment | 0~45℃, relative humidity 80% or below( at 35°C ),no condensation |
| Standard Accessory | AC adapter, lithium battery, manual, color management software, driver software, manual electronic version, color Management tutorial, data cable, black and white correction tube, portable bag |
| Gloss calibration tile | |
| Optional Accessory | Measurement area locator |
| External Dimension
(L*W*H)) | 181*73*112mm |
| Net Weight | About 0.8kg(excluding battery’s weight) |
-
